TT-R110

Key Features

Features Gallery
Image Thumbnail
  • alt

    110cc 4-stroke engine with semi-automatic gearbox

    The TT-R110's punchy and reliable 110cc, 4-stroke engine has been designed for smooth and strong performance – making this mid-sized youth bike a joy to ride. And with its semi-automatic 4-speed gearbox, the TT-R110 is an ideal choice for new as well as more advanced riders.

  • alt

    Long-travel front and rear suspension

    The TT-R110 is equipped with rugged suspension systems that are designed to ensure riding comfort and easy handling when riding off-road. At the front, the sturdy telescopic forks give plenty of wheel movement, while the single-shock monocross rear suspension offers smooth and progressive travel.

  • alt

    Smooth-action drum brakes and off-road tyres

    For reliable stopping power, the TT-R110 has drum brakes at the front and rear, and their simple design makes for easy maintenance. Special off-road-pattern tyres make this mid-sized youth bike a strong performer in the dirt, and the 14inch front wheel and 12inch rear wheel help to handle uneven terrains.

  • alt

    Sharp and lightweight motocross-style bodywork

    Check out the TT-R110's bodywork and it's clear that the sharp lines of this stylish 4-stroke have been inspired by our MXGP-winning YZ race bikes. Finished in Yamaha’s dynamic Icon Blue colour scheme, the fenders and fuel tank panels are made from ultra-tough polypropylene for minimum weight and maximum strength.

  • alt

    Forward-inclined cylinder and high-level exhaust

    The 110cc 4-stroke engine features a forward-inclined, air-cooled SOHC cylinder that allows easy access for cleaning and routine maintenance. This configuration also helps to centralise mass, for easy handling. And for low noise output, the TT-R110 has a large-capacity, high-level exhaust fitted with a heat shield.

  • alt

    Fun to ride

    When the TT-R110 was designed, the goal was to make a bike that was fun to ride and simple to own – making life easy for kids and parents. Features like the electric and kick start, semi-automatic gearbox, air-cooled engine and drum brakes mean that this rider-friendly youth bike is the leading choice for kids and parents who are new to motorcycling.

Technical Specifications

Download Factsheet
  • Engine
    Engine type
    SOHC, Single cylinder, 4-stroke, Air-cooled, 2-valves
    Displacement
    110cc
    Bore x stroke
    51,0 x 54,0 mm
    Compression ratio
    9,3 : 1
    Lubrication system
    Wet sump
    Clutch Type
    Wet, Multiple Disc
    Ignition system
    CDI
    Starter system
    Electric and kick
    Transmission system
    Constant Mesh, 4-speed
    Final transmission
    Chain
    Carburettor
    Mikuni VM16/1
  • Chassis
    Frame
    Steel tube backbone
    Caster Angle
    26° 00
    Trail
    60 mm
    Front suspension system
    Telescopic fork
    Rear suspension system
    Swingarm
    Front travel
    115 mm
    Rear Travel
    110 mm
    Front brake
    Mechanical leading trailing drum brake, Ø95 mm
    Rear brake
    Mechanical leading trailing drum brake, Ø110 mm
    Front tyre
    2,50-14 4PR
    Rear tyre
    3,00-12 4PR
  • Dimensions
    Overall length
    1.565 mm
    Overall width
    680 mm
    Overall height
    920 mm
    Seat height
    670 mm
    Wheel base
    1.080 mm
    Minimum ground clearance
    180 mm
    Wet weight (including full oil and fuel tank)
    72 kg
    Fuel tank capacity
    3,8 L
    Oil tank capacity
    1,0 L
