YFM700R SE

Key Features

Features Gallery
Image Thumbnail
info Professional rider with advanced skill depicted on a closed area.
  • alt

    High power, big torque

    Yamaha 4-stroke ATVs provide high levels of torque even at low rpm that ensures terrain-hugging traction, even in difficult conditions. The YFM700R's engine produces high levels of power and torque - and its fuel injection system gives increased fuel economy and reduced emissions.

  • alt

    Extra-strong hybrid chassis

    For the kind of strength that withstands every knock and bump, the state-of-the-art hybrid chassis combines a steel front section with an aluminium rear section and a detachable subframe. And for comfortable and controllable handling, there's a lightweight cast aluminum swing arm operating an adjustable shock with optimized damping settings.

  • alt

    5-speed transmission with reverse

    To optimize the remarkable performance potential of the high powered engine, the YFM700R drives through a slick-shifting 5-speed transmission. Whatever the terrain, this durable gearbox and smooth multi-plate clutch gives you total control - while the reverse gear gives added maneuverability in tight situations.

  • alt

    Adjustable suspension

    The long-travel front suspension is set up with KYB Piggybacks shocks at the front and rear, both with fully adjustable Hi and Low speed compression - and single rebound stroke. You can tune the suspension to your personal preference to suit your ride on all types of surfaces. The large diameter 22-inch front tyres soak up the bumps and are precise on your steering input.

  • alt

    Lightweight aluminium wheels and calipers

    Aluminium wheels and compact calipers contribute to the YFM700R's SE low unsprung weight that ensures responsive suspension characteristics. Operating on ventilated discs, the 2-piston front brake calipers - combined with the YFZ450R-type 2-piston rear caliper - deliver smooth and controllable stopping power for riding confidence.

  • alt

    Ergonomic design

    Piloting an ATV is a fun, physical activity that uses unusual combinations of muscles. Yamaha ATVs are designed to be straightforward to use, and comfortable for the widest possible range of body shapes and sizes. The front end design gives plenty of knee clearance for improved body movement, while retaining the aggressive, streamlined YFM700R SE styling.

  • alt

    Special edition

    The race-oriented YFM700R SE comes with an exclusive range of performance enhancing equipment, including a high compression cylinder head, race-spec fuel mapping and high-lift cam. And with its high-tensile steel upper 'A' arms and fully-adjustable front piggyback shocks, this high-tech ATV comes ready to win!

Technical Specifications

Download Factsheet
  • Engine
    Engine type
    Single cylinder, Liquid-cooled, 4-stroke, 4-valves
    Displacement
    686cc
    Bore x stroke
    102.0 mm x 84.0 mm
    Compression ratio
    10.0 : 1
    Lubrication system
    Dry sump
    Fuel system
    Fuel injection, 44 mm
    Ignition system
    TCI
    Starter system
    Electric
    Transmission system
    5 speed & reverse, wet multiplate clutch
    Drive system
    2WD
    Final transmission
    Sealed O-ring chain, eccentric adjustment
  • Chassis
    Front suspension system
    KYB Piggy Back with Hi and Low speed compression & single rebound adjustment, Independent double wishbone, threaded preload adjustable spring, 230 mm wheel travel
    Rear suspension system
    KYB Piggy Back with Hi and Low speed compression & single rebound adjustment, threaded preload adjustable spring, Cast aluminium swingarm, 256 mm wheel travel
    Front brake
    Dual ventilated disc with hydraulic twin piston callipers
    Rear brake
    Ventilated wave-type disc with hydraulic callipers
    Front tyres
    AT22x7-10
    Rear tyres
    AT20x10-9
  • Dimensions
    Overall length
    1,845 mm
    Overall width
    1,155 mm
    Overall height
    1,115 mm
    Seat height
    830 mm
    Wheelbase
    1,280 mm
    Minimum ground clearance
    115 mm
    Wet weight (including full oil and fuel tank)
    192 kg
    Fuel tank capacity
    11.0 litres
  • Additional features
    SE/LE Features
    Painted Body / Piggy back, 3 way adjustable shock specs / wheel trim
Professional rider(s) with advanced skill(s) depicted in a closed area.
