Technical Specifications
Download Factsheet-
Engine
- Type / Displacement
- 4 Stroke / 192cc
- Cylinders
- 1-Cylinder
- Cooling
- air-cooled
- Bore x stroke
- 70.0 mm x 55.0 mm
- Carburation
- BS-25 Mikuni CV Carburettor
- Intake design
- 1-valve
- Ignition system
- CDI
- Exhaust
- 1-valve
- Clutch / transmission
- CVT
- Disc brake system
- Hydraulic disc
-
Suspension
- Front suspension system
- Double Wishbone
- Front shocks
- Hydraulic Twin Tube
- Front travel
- 114 mm
- Rear suspension system
- Slide-rail, adjustable torsion spring
- Rear shocks
- Hydraulic Twin Tube
- Rear Travel
- 216 mm
-
Measures / Dimensions
- Overall height
- 914 mm
- Overall length
- 2,134 mm
- Overall width
- 914 mm
- Track W x L x H (")
- 10 " x 93 " x 1,0 "
- Track W x L x H (mm)
- 254 mm x 2,363 mm x 25.4 mm
- Track Type
- Camso® Cobra
- Ski stance (ctr. to ctr.)
- 775 mm
- Fuel tank capacity
- 8.2 L
-
Features
- Electric start
- Electric & Recoil
- Reverse
- N/A
- Hand & thumb warmers
- 2 position Handwarmer
- Headlight watts, type
- 12V/55W Halogen
- DC output
- N/A
